Parallel stack ports
Four Cat 5 ports
1
/
of
1
Magnum - Sensata
Advanced Router Remote - required for parallel stacking of the MS-PAE
Regular price
$689.00 CAD
Regular price
$723.00 CAD
Sale price
$689.00 CAD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Advanced Router Provides Complete System-level Connectivity and Programming
Quickly and easily connect multiple inverter/chargers, charge controllers, and accessories without individual programming using the Magnum Energy ME-ARTR Router. This advanced router is designed to provide system-level connectivity and programming for large Magnum Energy installations. One ME-ARTR can accommodate up to four MS-PAE or MS-PE inverter/chargers in parallel and program up to seven PT-100 solar charge controllers at once. The advanced router can also handle two ME-AGS modules, multiple ME-BMK monitors, and one ME-ARC or ME-RC remote.
Available ME-ARTR Videos:
- Introducing the ME-ARTR Advanced Router
- ME-ARTR Advanced Router System Setup
- Configuring your Inverter Settings with the ME-ARTR Router
- Configuring your Charger Settings with the ME-ARTR Router
- Setting up your ME-AGS with your ME-ARTR Advanced Router
- Setup the ME-BMK Battery Monitor Kit with the ME-ARTR Advanced Router
- Setting up the PT-100 Charge Controller with the ME-ARTR Router
- ME-ARTR and the Meter Screens for the PT-100 Charge Controller
- Auxiliary Relay Setup with the ME-ARTR
- How to Start an Equalization Charge with the ME-ARTR
- Setup AC Input Control with the ME-ARTR
|
|
|
Aux relay
One 2-wire terminal
|
|
Comm/accessory ports
Six
|
|
MicroSD card slot
One
|
|
Power consumption (on)
2.8 watts
|
|
Available battery settings
Bulk, Absorb, Float, EQ, Bulk Always
|
|
Available battery types
AGM1, AGM2, Flooded, GEL, CC/CV, Custom
|
|
Communication default battery type
Flooded
|
|
Warranty
One year. Five years if installed on a Magnum energy MMP or MP System
|
|
Ambient temperature range
-4 °F to 149 °F (-20 °C to 65 °C)
|
|
Dimensions (WxHxD)
8.94” x 6.63” x 1.94” (22.7 cm x 16.8 cm x 4 cm)
|
